AKG PCC160 Pressure Zone Microphone (PZM)

AKG Crown PCC160 Supercardioid Condenser Boundary Microphone / PZM
Pressure Zone Microphone
Made in USA

The PCC160 is a professional boundary layer microphone and an industry standard stage floor microphone. It´s capable of withstanding up to 120dB SPL without distortion. A bass-tilt switch allows the user to tailor the low-end response for particular applications.

PCC® (Phase Coherent Cardioid®) technology uses diaphragms so small that any phase cancellations are above the audible range. This results in a wide, smooth frequency response free of phase interference. The PCC160 uses a supercardioid polar pattern that improves gain before feedback and reduces unwanted room noise from the rear.

Audio frequency bandwidth 50 - 18000 Hz
Equivalent noise level 22 dB-A
Sensitivity 22 mV/Pa
Signal to Noise 72 dB-A
Recommended load impedance 2000 Ohms

Powering Interface
Voltage 12 to 48 V

Length 170 mm
Width 80 mm
Height 20 mm
