ART MX822 Eight-Channel Stereo Rackmount Mixer

Overview

The ​ART MX822 Eight Channel Stereo Rackmount Mixer​ is a versatile eight input mixer for studio, live sound or installation applications. Each input accepts a mono or stereo signal and provides independent level, pan and effects send controls. Channel One includes a switchable mic/line source select and the XLR mic connector provides switchable phantom power.



Multiple MX822s may be chained for additional inputs using common 1/4-inch TRS cables. External effects processors can be linked in and mixed with independent level controls. A front panel headphone jack with separate level control allows independent monitoring.



Key Features

-Eight stereo/mono input channels with individual level, pan and effects send controls

-Front panel 1/4-inch stereo (TRS) headphone jack with amplifier and independent level control for

-Switchable balanced microphone XLR or 1/4-inch inputs on Channel One

-Separate green and red LED signal and clip indicators for each input channel

-Balanced left and right XLR main outputs

-Rugged 1U rack mount steel case

-External effects loop with independent send and return controls

-output monitoring

-Switchable low noise +48V phantom power for microphone input

-Six level left and right main output metering including clip indicators

-Multiple units may be chained together for additional inputs
