Garmin Striker Vivid 4cv CHIRP Fishfinder and GPS

THE CHOICE IS YOURS
See fish and structure in maximum detail when you pick your display color, your location and your sonar for your day on the water with the STRIKER Vivid 4cv fishfinder with transducer.

A new way to see what’s under the water.

CLEAR, COLORFUL SONAR
Choose from 7 new vivid color options to see fish and structure in maximum contrast and clarity on your 4” fishfinder.

BUILT-IN SONAR
Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.

WAYPOINT MARKING
To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.

HIGH-SENSITIVITY GPS
Plan and create routes and view your boat’s speed on your fishfinder using high-sensitivity GPS.

QUICKDRAW CONTOURS
Nobody knows the waters you fish better than you. With the STRIKER Vivid 4cv fishfinder, you can store up to 2 million acres of maps with 1’ contours2.

INCLUDED HARDWARE
The STRIKER Vivid 4cv fishfinder includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.

Specifications
General
PHYSICAL DIMENSIONS 3.9'' x 6.9'' x 1.8'' (9.8 x 17.4 x 4.5 cm)
DISPLAY RESOLUTION 272 X 480 pixels
DISPLAY TYPE QSVGA
WEIGHT
0.7 lbs (0.3 kg)
WATER RATING IPX7
TRANSMIT POWER 300 W (RMS)
Sonar Features & Specifications
DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes
DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes
FREQUENCIES SUPPORTED
Traditional: 50/77/200 kHz
CHIRP (mid and high)
ClearVü 260/455/800 kHz
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes
WATER TEMPERATURE LOG AND GRAPH Yes
Fishfinder Features
SPLIT-SCREEN ZOOM Yes
ULTRASCROLL® (DISPLAYS FISH TARGETS AT HIGHER BOAT SPEEDS) Yes
FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) Yes
AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER, MAXIMIZES TARGETS) Yes
ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) Yes
A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) Yes
WATER TEMPERATURE SENSOR INCLUDED Yes
Additional
ADDITIONAL
One 4-pin transducer port
Quickdraw Contours
Integrated GPS
Mark Waypoints
Course over Ground (COG)
Current draw @ 12V: 0.40A
Waypoints: 5,000
Track Log: 50,000 points; 50 saved tracks
Routes: 100

What is in the box:
Striker Vivid 4cv fishfinder
GT20-TM trasducer
Tilt/swivel mount
Power cable/data cable
Hardware
Documentation
1 year warranty
