Hisense AN20DBG 2.0HP Aircond with Installation

New unit.

35% deposit required upon order confirmation.

Include standard installation.

Installation within 3 working days.

Aircond, Air Cond Aircon Air Con. 2.0 HP 2 HP 2HP
Penyaman Udara
Penghawa Dingin

R32 Standard Air Conditioner (DBG)
2.5HP | 2.0HP | 1.5HP | 1.0HP
Auto Clean
Ionizer Filter
Golden Fin
100% Copper Pipes
Warranty: General 2 years Compressor 7 years (from 2025)
Energy Rating: 3 Stars

Ratings
Model No. AN20DBG
Type Non-Inverter
HP 2.0HP
Cooling Capacity (Btu/h) 18,000
Rated Input-Cooling (W) 1,730
Air Circulation (m3/h) 950
EER for Cooling W/W 3.05
Energy Class Cooling 3 Stars
Average Energy Consumption/Year kWh 2,675
Refrigerant Type R32
Refrigerant charge volume g 1,000
Indoor Unit Noise Level (Sound Pressure) High(dB (A)) 45
Low(dB (A)) 36
Outdoor Unit Noise Level (Sound Pressure) dB (A) 56

Power Supply
Model No. AN20DBG
Voltage, Frequency V 220-240V~,50Hz
Phase 1P
Rated Current Cooling (A) 7.5
Maximal Pipe Length m 25
Maximal Heights’ Interval m 10
LRA A 38
Degree of Protection (IN/OUT) IP IPX0 / IPX4

System
Model No. AN20DBG
Compressor Type Rotary

Pipe Diameter
Model No. AN20DBG
Liquid Pipe (inch) 1/4
Gas Pipe (inch) 1/2

Features (General)
Model No. AN20DBG
Super Quiet (19 dBA) –
Display LED
LCD Wireless Remote Controller Yes
Removable and Washable Panel Yes
Washable PP Filter Yes
24 Hours Timer Yes
3 Speed and Auto Indoor Fan Control Yes
Vertical Auto Swing Louver Yes
Horizontal Auto Swing Louver –
Sleep Operation Yes
Smart Function Yes
Super Function Yes
Auto Restart Yes
Dimmer Yes
2 Ways Draining Yes, Left and Right
Ionizer Filter Yes

Other Information
Model No. AN20DBG
Packaging Dimensions
W x H x D (mm)
Indoor Unit 1000 x 390 x 315
Outdoor Unit 940 x 385 x 630

Net Dimensions
W x H x D (mm)
Indoor Unit 934 x 325 x 244
Outdoor Unit 810 x 585 x 280

Gross Weight (KG)
Indoor Unit 14.5
Outdoor Unit 42.5

Net Weight (KG) Indoor Unit 12.5
Outdoor Unit 37.5

Standard installation inclusive upto 10 feet copper hose, for normal
residential / office unit installation, surcharge may apply should special
installation required.
