Indoor unit Indoor air flow (H) 845 (497) m3/h(cfm) Indoor Sound level (H/L) 43/33 dB(A) Dimension(W*D*H) 969x241x320 mm Packing (W*D*H) 1045x315x405 mm Net/Gross weight 11.9/15.2 Kg Outdoor unit Outdoor Sound level 56 dB(A) Dimension(W*D*H) 765x303x555 mm Packing (W*D*H) 887x337x610 mm Net/Gross weight 27.2/29.4 Kg Refrigerant Charge R32/650g Design pressure 4.3/1.7 MPa Refrigerant piping Liquid side/ Gas side Φ6.35/Φ12.7(1/4"/1/2") mm(inch) Max. refrigerant pipe length 25 m Max. difference in level 10 m Cooling Capacity 18,000(7,984~19,786) Btu/h Power consumption 1,650(570~1,890) W Running current 7.2(2.48~8.25) A CSPF(Cooling seasonal performance factor) 4.87 Wh/Wh Energy Efficiency Star Rating 4 Power supply 220-240V~,50Hz,1Ph ((power supply to indoor)) V,Hz,Ph Indoor-Outdoor connection wiring (Not included) 4x2.5 mm2 Power supply wiring (No Plug) 3x2.5 mm2 Thermostat type Wireless Remote Control (Wifi control, Wire control optional)
Standard installation inclusive upto 10 feet copper hose, for normal residential / office unit installation, surcharge may apply should special installation required.
Mr Chou
Barter Corner Tel : 1700-81-5236 Email : *** Other Terms & Conditions: Warranty 1 year internal parts, 5 years compressor *** Payment option: - Cash On Delivery
