Solar Inverter 12V 2200W

Y&H 2200W Solar Hybrid Inverter DC12V to AC230V, Off-Grid Pure Sine Wave Inverter with 80A MPPT Solar Charger AC Charger,Max PV 2000W DC55-450V Input,fit for 12V Lead-Acid/Lithium Battery

This is a multi-function inverter charger, combining functions of inverter, solar charger, and battery charger to offer uninterruptible power support with portable size.

Bulit in 80amp mppt controller, which integrates solar energy storage &means charging energy storage and AC sine wave output.It can be widely used in DC to AC areas, such as solar AC power system, vehicle system, RV power supply, security monitoring system, emergency lighting system, field power system, household power system, etc.

Features：
Pure sine wave inverter
Programmable supply priority for PV, battery or Grid
High PV input voltage range(55~450VDC)
Reduce the cost of solar panels
Built-in Max 80A MPPT solar charge
Compatibe with lithium-ion battery
Support BMS communication with Lithium battery
Smart battery charge design to optimize battery life
Overload, high temperature,inverter output short circuit protection Intelligent fan speed adjustment
Built-in anti-dusk kit for harsh enviromen(optional)
WIFI&GPRS available for IOS and androidCold start function

Technical Specifications:
2200VA Hybrid Solar Inverter
Model: SP-2200W-12V-M80A
Max.PV Input Power: 2000W
Voltage range: 55-450Vdc
Max. PV Input VOC: 450VDC
Starting voltage >60V
Recommended PV cable size: 16AWG
Max.charge current: 80A
Nominal Input Frequency: 50/60Hz
Output Power: 1800W
surge Capacity: 3600W
fit for 12V Lead-Acid (Seal, AGM,Gel, Flooded) and Lithium battery
