Bar Bender & Bar Cutter

Bar Bender Description:

*Model:TKBB-32,TKBB-42 &TKBB-52
*Maximum Bar Diameter (mm):32,42 &52
*Engine:Vikyno RV-70,Vikyno RV-125 &Vikyno RV-165
*Engine Type:Horizontal, water-cooled 4 cycle Diesel Engine
*Output (hp/rpm):7 / 2400,12.5 / 2400 & 16.5/2400
*Roller Size (mm):Ø64, Ø75, Ø85, Ø95, Ø98 Ø110, Ø120, Ø125, Ø135, Ø150 & , Ø190
*Weight (kg):650,950 & 1280
*Dimension (mm) L x W x H:1170 x 900 x 750(Type:32) , 1375 x 1010 x 935(Type:42) &1750 x 1150 x 1150(Type 52)


Bar Cutter Description:

*Model:TKBC-32,TKBC-42&TKBC-52
*Maximum Bar Diameter (mm):32,42&52
*Engine:Vikyno RV-70,Vikyno RV-125 &Vikyno RV-165
*Engine Type:Horizontal, water-cooled 4 cycle Diesel Engine
*Output (hp/rpm):7 / 2400,12.5 / 2400 & 16.5/2400
*Weight (kg):600,950 & 1280
*Dimension (mm) L x W x H:1300 x 660 x 750(Type 32),1610 x 685 x 800(Type 42) &1800 x 1800 x 1000(Type 52)

*Machine available in engine type & motor type
